| Glovebox House |
| House | Material: Stainless steel type 304, thickness 3mm |
| Inside surface: Brushed finish |
| Outside surface: Enameled, White |
| Inside dimension: L1220 * W750 * H900mm |
| Window | Safety glass with thin film, thickness 8mm |
| Glove port | POM, O ring sealed, 2 ports |
| Gloves | 1 pair, Butyl, thickness 0.4mm, Dia. 8 inch x length 32 inch |
| Dust filter | 0.3 micron,1 gas inlet and 1 gas outlet filter included |
| Shelves | 2 layers shelves inside, height adjustable |
| Light | LED light front mounted |
| Feedthrough | DN 40 KF: several pieces Electrical feedthrough: 1 electrical plug for inside |
| |
| Vacuum Chamber |
| Big Antechamber |
| Chamber | Inside dimension: φ360mm x L600mm |
| Material: Stainless steel type 304 |
| Surface: Brushed finish inside and Painted white outside |
| Accessories | Door: double door, anodized aluminium Material: Stainless steel type 304 Thickness: 10mm |
| Manometer: Analog display |
| Control | Manual |
| Mini Antechamber |
| Chamber | Inside dimension: φ150mm x L300mm |
| Material: Stainless steel type 304 |
| Surface: Brushed finish inside and Painted white outside |
| Accessories | Door: double door, anodized aluminium Material: Stainless steel type 304 Thickness: 10mm |
| Manometer:Analog display |
| Control | Manual |
| |
| Gas Purification |
| Purifier | Function: Removal of H2O and O2 |
| Container material: Stainless steel type 304 |
| Absorber unit: Copper catalyst: 5Kg Molecular sieve: 5 Kg |
| Capacity of purifying: Removal of 60L O2, Removal of 2Kg H2O |
| H2O and O2: less than 1ppm |
| Gas Circulation | Working gas: Nitrogen, Argon and Helium |
| Blower: 90m3/h |
| Regeneration | Operation: Auto. PLC controlled Regeneration. |
| Regeneration gas: working gas / H2 mixture (H2: 5-10%) |
| Pump | Type: 12m3 /h Rotary vane pump, Oil mist Angle valves, Gas ballast control. |
| Valves | Main valves: DN 40 KF electro-pneum. Angle valves |
| |
| Controlling System |
| Function | Includes self-diagnosis, electric failure and restart, pressure controlling and self-adapt, circulation controlling, code protection, union controlling adopts, SIEMENS PLC touch screen etc. |
| Pressure controlling | The pressure in the box is controlled by PLC, the pressure can be settled between +/- 10 mbar, while beyond +/- 12 mbar the system will automatically protect itself. |
| Foot switch | Controlling the pressure, easy to raise or depress the pressure |
| |
| Accessories |
| Moisture Analyzer | Measuring Range: 0~500ppm, display by PLC |
| Oxygen Analyzer | 0~1000ppm, display by PLC |
| |
| Internet of things system |
| Function | -
Login control system from WeChat Public Number. -
Login control system by scanning QR code. -
Real-time monitoring of device status. -
Data backup and historical data query. -
Alarm message informed by SMS or Email. -
Remote debugging and fault diagnosis. -
One key to contact customer service. Check the help manual online. |
